Ormesa Grillo Anterior Gait Trainer

Description

Ormesa Grillo Anterior comes with 2 model options:

1. Ormesa grillo anterior gait trainer/walk trainer is designed to generate and help the step pattern, to train the pelvis and trunk to keep their balance, to organize a wider structured vision of space of distance and of the user’s surroundings in his upright position, to develop physical self-sufficiency and psychological independence by experimenting the possibility of acting alone without the help of other people.
2. Ormesa grillo anterior gait trainer, super complete allows the client to concentrate his/her residual abilities on walking. Grillo gait trainer comes with wide range of components and supports which offer maximum versatility. Grillo trainer available in open-back design which accommodates easy ingress and egress and can be in both forward or rear facing.

The product comes standard with:

• Horizontal bars
• Gait trainer frame
• Multi axis hardware
• Padded & adjustable pelvic support
• Pelvic Harness; ergonomic color coded harness
• Anterior handle bar adjustable in height and incline



Features



• Chest and pelvic supports: Padded and adjustable
• Ergonomic harness: Breathable, adjustable, and removable
• Arm supports: Adjustable in height, direction, depth, tilt and inclination
• Easy transport: Grillo folds into a small compact unit easy for transport
• Quick adjustment: Grillo adjusts easily and tool-free and allows for quick, easy, and accurate adjustment
• Exclusively-designed wheels: Include an anti-reverse lock, adjustable drag, breaks, and directional locks



Specifications



Ormesa grillo gait trainer
Technical features	One/Two	Three/Four	Five
Max load	99 lbs.	198 lbs. *	242 lbs.
User height	35″ – 53″	43″ – 65″	59″ – 75″
Total weight of unit	36 lbs.	43 lbs.	51 lbs.
* in case user weight ≥ 132 lbs. , for the version including trunk support, the use of pelvic harness highly recommended.
Support dimensions	One/Two	Three/Four	Five
Support circumference (A)	23.6″ – 33.9″	29.1″ – 47.2″	33″ – 55″
Chest support to floor (B)	27″ – 39″	30″ – 49″	32″ – 56.3″
Pelvic support to floor (C)	19″ – 33″	24.8″ – 46″	24.8″ – 46″
Overall length (D)	29.2″	35.8″	43.7″
Overall width (E)	25.6″	29.9″	31.5″
