Ki Mobility Catalyst 5 Ultralight Folding Manual Wheelchair

Description

Ki Mobility Catalyst 5 ultralight folding manual wheelchair is constructed from ultra-lightweight 7000 series aluminum, it is arguably the best choice in high-performance folding wheelchairs.

Ki Mobility Catalyst comes with several model options like:

1. Ki Mobility Catalyst 5TTL Ultralight Folding Manual Wheelchair
2. Ki Mobility Catalyst 5Vx Ultralight Folding Manual Wheelchair
3. Ki Mobility Catalyst 5 Ultralight Folding Manual Wheelchair
4. Ki Mobility Catalyst 5Ti Ultralight Folding Manual Wheelchair

The catalyst difference
Catalyst 5 takes advantage of all of the “Catalyst Difference” design features to allow you to fit, adjust and ride with confidence. A defining characteristic of each chair is its axle plate.

Standard and curved axle plates
Catalyst 5 provides adjustment of Center of gravity (CG). Both axle plate options, standard and curved, are machined from Billet 6061-T6 aluminum and offer finite adjustment of the CG and rear seat height. 3/16″ of CG adjustment over a 3 ½” range is a snap with the innovative 3D locking index washer design. The standard axle plate offers 1″ adjustments in rear-seat height and 1° adjustments of wheel camber while the curved axle plate offers a more discrete ½” of fine tuning adjustments in the rear seat.

Front frame styles
Catalyst 5 offers the option of a swing away front end featuring our patented footrests or 70° or 80° fixed frames. The swing away hangers come in 4 bends (60°, 70°, 80° & 90°) are light and easy to use and so strong.

Wheelchairs are about wheels
The Catalyst 5 offers Ki Mobility’s full line of specially designed Ki spoke wheels with precision machined hubs and hard anodized handrims. Utilizing straight pull spokes this wheel promotes a stiffer and stronger wheel while the hard anodize handrim is resistant to scratching so they keep that “NEW” look longer. It also offer the full array of industry standard wheels and casters such as Spinergy, Natural Fit, Frog Legs and Topolino.

Mags can be high performance too
Ki Mobility proudly offers the ultra-sleek and lightweight X-Core mags. These wheels have far greater stiffness and rigidity than conventional mags while keeping the weight to only 1 lb. more than spokes.

300 lb. Standard weight capacity
Catalyst 5 is the light and strong folding wheelchair on the market with a 300 lb. standard weight capacity! A heavy duty option is also available.

Specifications

Ki Mobility Catalyst 5 ultralight folding manual wheelchair
Weight	23 lbs.
Seat width	14″ – 22″
Seat depth	14″ – 20″
Front seat height	13.5″ – 21″
Weight capacity	300lbs/350lbs heavy duty
Camber	0°, 2°, 4°
Rear seat height	11.5″ – 19.5″
Top frame tubing size	1″
Bottom frame tubing size	1.125″
Ansi Resna WC-19 transit approved	Yes
